GENERAL DIMENSIONS				CSS550
A-Overall   Operating Height				4058	mm
B-Bucket   Hinge Pin Height				3077	mm
C-Cab Top   Height				2007	mm
D-Max Level   Height of Shovel Bucket Bottom				2908	mm
E-Length   without Bucket				2700	mm
F-Length   with Bucket				3413	mm
H-Max Dump   Height				2303	mm
J-Dump   Distance				675	mm
M-Wheel Base				999	mm
Q-Angle of   Departure				23	°
P-Ground   Clearance				185	mm
W-Tire Edge   Width				1740	mm
X-Bucket   Edge Width				1780	mm
SPECIFICATIONS				CSS550
Rated Load				750	kg
Tipping Load				1500	kg
Operating   Weight				3003	kg
Bucket Capacity				0.35	m³
Fuel Tank   Capacity				88	L
Hydraulic   Tank Capacity				70	L
Engine
Model				Perkins
				Kubota
				Xinchai
Output Power				47.8/35.7	Hp/Kw
				49.5/36.5	Hp/Kw
				50/36.8	Hp/Kw
Rated Speed				2600	RPM
				2600	RPM
				2650	RPM
Cooling   Method				Water
Performance
Operating Mode				Hydraulic
				Mechanic
Tire				10.0-16.5
Max Speed				12	Km/H
				12	Km/H

Air Conditioner
