TRANSPORTATION				Standard Dipper	Extendible Dipper
Total Length	mm		6230	6230
Boom Height	mm		3570	3580
Total Width	mm		2300	2300
Wheel Base	mm		2150	2150
Cabin Height(with A/C)	mm		2970	2970
Operating Weight	kg		8200	8720

LOADING SPECIFICATION				Standard Bucket	4 in 1 Bucket
Rated Bucket Capacity	m³		1.0	0.9
Max. Dumping Clearance	mm		2650	2534
Max. Dumping Reach	mm		1220	1178
Dig Depth	mm		218	218
Drawback Angle at Ground Pos	°		40	39.5
Bucket Upward Angle at Max. Working Height	°		45	44.5
Max. Breakout Force	kn		≥40	≥40
Rated Lifting Force	kn		≥25	≥25
Rise Time	s		5.1	5.1
Fall Time	s		4.9	4.9
Tilting time	s		0.9	0.9

EXCAVATING SPECIFICATION				Standard Dipper	Extendible Dipper
Rated Backhoe Bucket Capacity	m³	Extend	/	0.2
Rated Backhoe Bucket Capacity	m³	Retreat	0.2	0.2
Max.Excavating Depth	mm	Extend	/	5410
Max.Excavating Depth	mm	Retreat	4235	4242
Max.Excavating Force	kn	Extend	/	＞57
Max.Excavating Force	kn	Retreat	＞57	＞57
Max.Excavating Radius	mm	Extend	/	6484
Max.Excavating Radius	mm	Retreat	5378	5386
Max.Dump Height	mm	Extend	/	4299
Max.Dump Height	mm	Retreat	3519	3541
Max.Outbreak from Mid of Rear Axle	mm	Extend		7890
Max.Outbreak from Mid of Rear Axle	mm	Retreat	6785	6792
Max.Outbreak at the Max Dump Height	mm	Extend		2943
Max.Outbreak at the Max Dump Height	mm	Retreat	2032	2013
Turing Angle	°		180	180
MIN.TURNING RADIUS AT THE OUTER OF FRONT WHEEL
2WD	mm			3790
4WD	mm			4300
TYRE
Front Tire				14-17.5NHS-14PR
Rear Tire				19.5L-24-12PR R-4

ENGINE
Brand		Weichai	Cummins	Perkins
Model		WP4G95E221	4BTA3.9	1104D-44T
Type		Four-stroke,direct injection,turbo charge
Rated Speed	rpm	2200	2200	2200
Rated Power	hp/kw	95/70	112/82	100/74.5
Peak Torque	n.m	380	460	392
TRANSMISSION
Brand			CARRARO
Front Axle		Swing turn,oscillating angle is 22°
Rear Axle		Braking axle with wet-type
Min.Ground Clearance	mm		335
Driving Break		Electric-hydraulic control,built-in wet-type brake block
HYDRAULIC SYSTEM
Loading Pressure	mpa		20
Excavating Pressure	mpa		20
Steering Pressure	mpa		15
Output Pressure	mpa		16
Rated Flow	l/mini		110
TRAVEL SPEED			Forward	Backward
Gear 1	km/h		5.8	5.8
Gear 2	km/h		10.5	10.5
Gear 3	km/h		20.1	20.1
Gear 4	km/h		40.2	40.2

Air Conditioner
